Description
Technical specifications:
Spesifikasi
- Stereo Power (8Ω) : 2x2000W
- Stereo Power (4Ω) : 2x3800W
- Stereo Power (2Ω) : 2x4760W
- Bridge Power (8Ω) : 6800W
- Bridge Power (4Ω) : 9520W
- Power : PFC Power
- Rated Power Demand : 100-240 V ± 10%, 50/60 Hz
- Operation Voltage : 90V-270V
- Gain, Sensitivity : 32dB, 35dB, 38dB, 41dB
- Frequency Response : 20Hz-20kHz (1 W @ 8Ω , ± 0,5dB
- Signal-To-Noise Ratio : >110 dBA (20Hz-20kHz, A weighted)
- Input Impedence : 10kΩ balanced
- Total Harmonic Distortion : <0,5% from 1 W to full power
- (THD) : (Typical value<0,05%)
- Intermodulation Distortion : < 0,5% from 1 W to full power
- (IMD) : (Typical value<0,05%)
- Damping Factor (8 ohms) : >5000 @ 20-2000 Hz
- Slew Rate : 50 V/us @ 8Ω
- Signal In-Connection : One balanced XLR (with lock) female and one balanced XLR male per channel
- Signal Out-Connection : One SPEAKON per channel connect to loudspeakers
- Multiple-Functions Switch : Two sensitivity switches, one mode switch and one clip switch
- Dimensions : 482x44x470mm
- Net Weight : 11.5Kg
Datasheet yang kami sediakan ini merupakan datasheet dengan spesifikasi yang diperuntukkan sebagai petunjuk professional. Apabila Anda belum tahu tentang spesifikasi dan tidak mengerti mengenai apa yang ada dalam datasheet yang kami sediakan, kami menyarankan agar Anda konsultasi dengan professional yang menangani audio tools.
